| Mass Parameters | Total Weight (kg) | 25000 |
| Rated Loading Weight (kg) | 12770 |
| Size Parameters | Overall Dimensions (mm) | Length | 8350 |
| Width | 2496 |
| Height | 3450 |
| Distance between Axles (mm) | 3800+1350 |
| Performance Parameters | Max. Driving Speed (km/h) | 75 |
| Economic Speed (km/h) | 60 |
| Recommended Configuration | Engine (EURO II) | WD615.69 |
| Gearbox | HW19710 |
| Rear Axle | HC16 |
| Oil Tank (L) | 300 |
| Suspension (front/rear spring) | 10/12 |
| Tire | 12.00R20 |
| hohan 8x4 dump truck |
| hohan |
| cnhtc truck price |
| cnhtc dump truck |
| cnhtc |
HOWO AND HOHAN SPARE PARTS
| WG2229220001 | PIN |
| WG2229220002 | PIN |
| WG2212220201 | REVERSE GEAR FORK SHAFT ASSEMBLY |
| WG2214220001 | FORK SHAFT |
| WG2214220002 | SLIDING PAD |
| WG2229220001 | PIN |
| WG2229220002 | PIN |
| WG2212220103 | REVERSE GEAR FORK SHAFT ASSEMBLY |
| WG2214220001 | FORK SHAFT |
| WG2214220003 | SLIDING PAD |
| WG2229220001 | PIN |
| WG2229220002 | PIN |
| AZ9003070346 | O RING |
| WG2229040003 | SPRING |
| WG2229040103 | SPACING BUSH |
| AZ2210020105 | INPUT SHAFT |
| WG2229020005 | BUSH |
| AZ2203020002 | OUTPUT SHAFT COVER |
| AZ9003070055 | OIL SEAL |
| WG2229020007 | RING |
| AZ2210030203 | VICE SHAFT GEAR 2GEAR |
| AZ2210030220 | VICE SHAFT |
| AZ2210030224 | VICE SHAFT GEAR 3 GEAR |
| AZ2210030226 | VICE SHAFT GEAR 4 GEAR |
| AZ2210030227 | VICE SHAFT TRANSMISSION GEAR |
| WG2210040002 | RETAING PIECE |
| WG2210040012 | RETAING PIECE |
| WG2210040210 | SLIDING BUSH |
| WG2229040003 | SPRING |
| WG2229040211 | PIN |
| AZ2225100001 | OUTPUT SHAFT |
| AZ9003821255 | SCREW |
| AZ9007970271 | GLUE |
| WG2225100002 | PLANET BRACKET FRONT |
| WG2229100001 | TRANSFER TORQUE SLEEVE |
| Q43875 | THRUST RING |
| WG2210100001 | SUN GEAR |
| WG2210100002 | SLEEVE |
| WG2210100003 | SLEEVE |
| WG2203100009 | ODOMETER CONNECTOR |
| WG2222100001 | OUTPUT SHAFT REAR COVER |
| AZ2208100003 | REAR BEARING ADJUSTING WASHERS |
| AZ2220100105 | REAR HOUSING |
| AZ9003070105 | OIL SEAL |
| AZ9003070800 | O RING |
| AZ9003071700 | O RING |
| AZ9003072503 | O RING |
| AZ9003076900 | O RING |
| AZ9003321118 | CYLINDRICAL ROLLER |
| AZ9003321820 | ROLLER BEARING |
| AZ9003326020 | ROLLER BEARING |
| AZ9003326218 | ROLLER BEARING |
| AZ9003326322 | ROLLER BEARING |
| AZ9003801187 | HEX HEAD BOLT |
| AZ9003870016 | NUT |
| AZ9003990024 | FLEXIBLE WASHER |
| AZ9003991056 | FLEXIBLE WASHER |
| AZ9003991125 | WIRE RETAING RING |
| AZ9003991130 | FLEXIBLE WASHER |
| AZ9007970242 | GLUE |
| WG2229003030 | BUSH |
| AZ2220010005 | BLUEPRINT HOUSING |
| WG2203010002 | OIL DRAIN PLUG |
| WG2229010002 | PLUG |
| AZ9003335500 | BALL |
| WG2222020001 | SHAFT COVER |
| AZ9003329309 | CYLINDRICAL ROLLER |
| Q43160 | SHAFT CIRCLIPS |
| Q5280514 | FLEXIBLE CYLINDRICAL PIN |
| WG2229030101 | PIN |
| AZ2210030203 | VICE SHAFT GEAR 2 GEAR |
| AZ2210030215 | VICE SHAFT |
| AZ2210030224 | VICE SHAFT GEAR 3 GEAR |
| AZ2210030226 | VICE SHAFT GEAR 4 GEAR |
| AZ2210030227 | VICE SHAFT TRANSMISSION GEAR |
| AZ9003329309 | CYLINDRICAL ROLLER |
| Q43160 | SHAFT CIRCLIPS |
| Q5280514 | FLEXIBLE CYLINDRICAL PIN |
| WG2229030101 | PIN |
| AZ2208040001 | ADJUSTING WASHER |
| AZ2210040206 | MAIN SHAFT GEAR 2 GEAR |
| AZ2210040207 | MAIN SHAFT REVERSE GEAR |
| AZ2210040224 | MAIN SHAFT GEAR 4 GEAR |
| AZ2210040225 | MAIN SHAFT GEAR 3 GEAR |
| AZ2210040230 | MAIN SHAFT GEAR1 GEAR |
| Q5280310 | PIN |
| WG2203040009 | BALL |
| Q150B0630 | HEX HEAD BOLT |
| AZ9007990001 | GLUE |
| Q72116 | CORE HOLE PLUG |
| WG2229003030 | BUSH |
| WG2229260001 | FORK SHAFT BRACKET |
| AZ9003991065 | SHAFT CIRCLIPS |
| AZ9003992065 | SHAFT CIRCLIPS |
| AZ9003993065 | SHAFT CIRCLIPS |
| AZ9003994065 | SHAFT CIRCLIPS |
| AZ9003995065 | SHAFT CIRCLIPS |
| WG2229020011 | ADJUSTING WASHER |
| WG2229020012 | ADJUSTING WASHER |
| WG2229020013 | ADJUSTING WASHER |
| WG2229040031 | ADJUSTING WASHER |
| WG2229040032 | ADJUSTING WASHER |
| WG2229040033 | ADJUSTING WASHER |
| WG2229040034 | ADJUSTING WASHER |
| WG2229040035 | ADJUSTING WASHER |
| WG2229040036 | ADJUSTING WASHER |
| WG2229040037 | ADJUSTING WASHER |
| WG2229040038 | ADJUSTING WASHER |
| WG2229040039 | ADJUSTING WASHER |
| WG2229040053 | ADJUSTING WASHER |
| WG2229040054 | ADJUSTING WASHER |
| WG2229040055 | ADJUSTING WASHER |
| WG2229040056 | ADJUSTING WASHER |
| AZ9003326308 | ROLLER BEARING |
| AZ9703290002 | PIN SHAFT |
| AZ9729290012 | REAR HOLE STOP RING |
| Q43135 | SHAFT CIRCLIPS |
| AZ9003071180 | O RING |
| AZ9003072120 | O RING |
| AZ9003073350 | O RING |
| AZ9003801042 | HEX HEAD BOLT |
| AZ9003900026 | PIN |
| AZ9003990062 | STOP RING |
| AZ9003990086 | STOP RING |
| AZ9007970242 | GLUE |
| AZ9710290002 | BUIGE REASON |
| AZ9710290004 | SLIDING BUSH |
| AZ9712290001 | GEAR FORK SHAFT |
| AZ9714290001 | FORK SHAFT |
| AZ9720290001 | PTO FRONT HOUSING |
| AZ9722290002 | AIR CYLINDER |
| AZ9729290002 | PAPER WASHER |
| AZ9729290003 | OUTPUT SHAFT COVER PAPER WASHER |
| AZ9729290004 | PRESSURE PLATE |
| AZ9729290005 | AIR CYLINDER PAPER WASHER |
| AZ9729290006 | SPACING BUSH |
| AZ9729290007 | SPRING |
| Q150B0860 | HEX HEAD BOLT |
| Q150B1030 | HEX HEAD BOLT |
| Q150B1032 | HEX HEAD BOLT |
| Q150B1060 | HEX HEAD BOLT |
| Q150B1230 | HEX HEAD BOLT |
| Q150B1245 | HEX HEAD BOLT |
| Q150B1250 | HEX HEAD BOLT |
| Q40112T16F9 | FLAT WASHER |
| Q40308 | SPRING WASHER |
| Q40310 | SPRING WASHER |
| Q40312 | SPRING WASHER |
| Q5220820 | PIN |
| AZ9720290002 | PTO REAR HOUSING |
| Q61902 | PLUG |
| AZ9003322216 | CYLINDRICAL ROLLER |
| AZ9710290001 | INPUT GEAR SHAFT |
| Q43130 | SHAFT CIRCLIPS |
| AZ9003322206 | CYLINDRICAL ROLLER |
| AZ9003322208 | CYLINDRICAL ROLLER |
| AZ9710290003 | OUTPUT GEAR SHAFT |
| Q43130 | SHAFT CIRCLIPS |
| AZ9003070050 | OIL SEAL |
| AZ9722290001 | OUTPUT SHAFT COVER |
| 190003326148 | Roller bearing |
| WG9014320137 | Driving cylindrical gear |
| WG9014320136 | Driven cylindrical gear |
| WG9014320257 | Bearing |
| WG1800 320077 | Tappet |
| WG2700 320037 | Bush |
| AZ9231320038 | "O" ring |
| WG288 730062 | "O" seal ring |
| 190003070026 | Seal ring |
| 190003078772 | Seal ring |
| AZ9231320261 | Transfixion shaft |
| WG9231320141 | Bearing block |
| Q5005055 | Split pin |
| WG9231326212 | Bearing |
| WG9012320103 | Bearing housing |
| WG9012320173-176 | Shim |
| WG9231320169 | Screw |
| Q150B0816 | Screw |
| Q5005055 | Split pin |
| WG9231340002 | Screw |
| WG9231340001 | Cover |
| 199112340029 | Planetary carrier |
| Q2541025 | Screw |
| 190003330148 | Ball |
| WG9012340004 | Bolt |
| WG99-934-013 | Needle |
| WG9012340075 | Washer |
| WG9012340077 | Washer |
| WG9012340122 | Planet gear |
| WG9012340005 | Sun gear |
| 190003326167 | Roller bearing |
| WG9012340029 | Gasket |
| WG9231340917 | Spacer ring |
| WG2212100001 | PLANET GEAR SHAFT |
| AZ2210100012 | PLANET RING |
| WG2229100007 | ROLLER SPACING |
| WG9003321118 | CYLINDRICAL ROLLER |
| AZ9003991056 | FLEXIBLE RETAINING RING |
| AZ2203100105+001 | PLANET CARRIER |
| WG2229100211 | SYNCHRONIZER SPRING |
| WG2229040302 | SYNCHRONIZER LOCKNG PAD BLOCK |
| WG2229040315 | MAIN SHAFT REAR LEADING OIL CONNECTOR |
| AZ2210040404 | MAIN SHAFT GEAR 2 GEAR |
| AZ2203040452 | GEAR 2/3 GEAR BLOCK |
| WG2229040327 | SYNCHRONIZER LOCKING BLOCK |
| AZ2210040402 | MAIN SHAFT GEAR 4 GEAR |
| WG2229040307 | SYNCHRONIZER SPRING |
| WG2229040301 | SYNCHRONIZER LOCKING BLOCK |
| WG2229040326 | SYNCHRONIZER LOCKNG PAD BLOCK |
| WG2229040310 | WASHER AND LOCKING PIECES |
| WG2229040314 | MAIN SHAFT FRONT LEADING OIL CONNECTOR |
| WG2203240019 | OIL PUMP ASSEMBLY |
| WG2203240018 | SHOWER HOSE |
| WG2203240017 | FILTER PIPE ASSEMBLY |
| WG9003073018 | O RING |
| WG2229240033 | WIRE RETAING RING |
| WG2229240032 | OIL PUMP HOUSING SEALING BUSH |
| WG2229010007 | SEALING RING |
| WG2203010008 | OIL FILTER ASSEMBLY |
| AZ9003070050 | OIL SEAL |
| AZ9003073350 | O RING |
| Q40112T16F9 | FLAT WASHER |
| 179100710069 | PRESSURE SWITCH |
| AZ2203240006 | PTO OIL INLET PIPE |
| Q72310 | SEALING WASHER |
